13.56Mhz High Frequency HF RFID Card ISO/IEC 14443A Standard 0.84mm

Brand Name:	Vionext
Model Number:	NFC013
MOQ:	100pcs
Packaging Details:	200pcs/samll inner box, 1000/3000/5000pcs per outer box
Payment Terms:	L/C, D/P, T/T, Western Union, MoneyGram,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Printing Options:

Offset Printing, Silk Screen Printing

Operating Temperature:

-20°C To +55°C

Write Endurance:

100,000 Cycles

Thickness:

0.84 Mm

Data Retention:

10 Years

Protocol:

ISO 14443A

Reading Distance:

Up To 10 Cm

Size:

85.5 X 54 Mm

Personalization Options:

Barcode, QR Code, Magnetic Stripe, Embossing

Frequency:

13.56 MHz

Chip Type:

HF RFID

Operating Distance:

≤100 Mm

Material:

PVC, PET, ABS

Application:

Access Control, Payment, Identification

Supply Ability:

500000pcs per month

Highlight:

13.56Mhz HF RFID Card

ISO 14443A HF RFID Card

ISO 14443A High Frequency RFID Card

Product Description

13.56MHz High Frequency (HF) RFID cards compliant with ISO/IEC 14443A are sophisticated contactless smart cards widely used in secure identification and payment applications. These cards represent a significant advancement over older LF RFID technology, offering enhanced security features and data storage capabilities.

Key Technical Characteristics:

Operating frequency: 13.56MHz
Read range: Typically 3-10 centimeters
Data transfer rate: Up to 848 kbps
Multiple memory options: 1K, 2K, 4K bytes
Supports both read and write operations
Advanced encryption capabilities (AES, 3DES)
Anti-collision functionality for multiple card reading

Security Features:

Unique serial number (UID) for each card
Mutual authentication between card and reader
Encrypted data transmission
Multiple security keys and access conditions
Protection against replay attacks
Secure messaging protocols

Common Applications:

Public transportation ticketing
Electronic payments
Government ID cards
Healthcare cards
Campus cards
Secure building access
Loyalty programs
Library management systems

The ISO/IEC 14443A standard ensures interoperability between different manufacturers' cards and readers, making it a globally accepted solution. The technology supports sophisticated applications through its segmented memory structure, allowing multiple applications to coexist on a single card securely.

These cards typically integrate MIFARE technology (such as MIFARE Classic, DESFire, or Ultralight), which provides various levels of security and functionality depending on the specific requirements. The cards can be customized with visual elements like printing, holograms, and other security features for additional physical security.

The combination of higher frequency, better data transfer rates, and advanced security features makes these cards ideal for modern applications requiring secure transactions and data storage. While more expensive than basic LF RFID cards, they offer significantly better value through their enhanced capabilities and security features, making them the preferred choice for many contemporary RFID applications.
